19′ JLG 1930ES Electric Scissor Lift

 19′ Electric Scissor Lift

Call for availability

(231) 775-4400

Reserve yours today!

Serving all of Northern Michigan including, Cadillac, Manton, McBain, Marion, Mesick, Lake City, and all surrounding areas.

Add to Wishlist
Compare
Category: Tags: , , , , , , , , , , , , , , , , , , , , ,

Description



JLG 1930ES Electric Scissor Lift

            Product Specs:

  • Machine Width: 2 ft 6 in. / 0.76 m
  • Platform Height: 18 ft 9 in. / 5.72 m
Power Source
Batteries 4 x 6V, 220 amp-hour
Charger 20 amp automatic (120V/240V – 50/60Hz)
General
Brakes Electric, Friction
Capacity – Hydraulic Reservoir 1 gal. / 4.73 L
Ground Bearing Pressure 109 psi / 7.63 Kg/cm2
Hydraulic Pump Fixed Displacement Gear
Machine Weight 2710 lb / 1229.24 kg
Performance
Drive Speed – Platform Elevated 0.50 mph / 0.80 km/h
Drive Speed – Platform Lowered 3 mph / 4.83 km/h
Drive System 24V Electric
Gradeability 25 %
Lift Time 26 sec.
Lower Time 30 sec.
Maximum Drive Height 18 ft 9 in. / 5.72 m
Maximum Lift Height 19 ft / 5.72 m
Platform Capacity – Extension 250 lb / 113.40 kg
Platform Capacity – Unrestricted 500 lb / 226.80 kg
Turning Radius – Outside 5 ft 9 in. / 1.75 m
Turning Radius – Inside 0 in. / 0 mm
Dimensional Data
Ground Clearance 4 in. / 0.09 m
Machine Height 6 ft 6 in. / 1.98 m
Machine Length 6 ft 2 in. / 1.87 m
Machine Width 2 ft 6 in. / 0.76 m
Platform Dimension A 2 ft 6 in. / 0.76 m
Platform Dimension B 6 ft 2 in. / 1.87 m
Platform Extension Length 3 ft / 0.9 m
Platform Height 18 ft 9 in. / 5.72 m
Platform Height – Lowered 2 ft 10 in. / 0.86 m
Platform Railing Height 3 ft 7 in. / 1.1 m
Tire Size 12.5 x 4 in
Wheelbase 5 ft 3 in. / 1.6 m
Reach Specifications
Platform Height 18 ft 9 in. / 5.72 m
Working Height 24 ft 9 in. / 7.54 m
Close

Key Features

  • Quieter, cleaner operation for a variety of environments
  • Electric drive and integrated components with only two hydraulic hoses and four hydraulic fittings on the entire machine will keep you on the job longer and reduce your operating costs by reducing chances for leaks and service calls
  • Narrow width fits through most standard doorways and tight aisles
  • Delivers 200% more battery life*
    *Compared to a competitive model under similar test conditions. Actual results may vary.
Power Source
Batteries 4 x 6V, 220 amp-hour
Charger 20 amp automatic (120V/240V – 50/60Hz)
General
Brakes Electric, Friction
Capacity – Hydraulic Reservoir 1 gal. / 4.73 L
Ground Bearing Pressure 109 psi / 7.63 Kg/cm2
Hydraulic Pump Fixed Displacement Gear
Machine Weight 2710 lb / 1229.24 kg
Performance
Drive Speed – Platform Elevated 0.50 mph / 0.80 km/h
Drive Speed – Platform Lowered 3 mph / 4.83 km/h
Drive System 24V Electric
Gradeability 25 %
Lift Time 26 sec.
Lower Time 30 sec.
Maximum Drive Height 18 ft 9 in. / 5.72 m
Maximum Lift Height 19 ft / 5.72 m
Platform Capacity – Extension 250 lb / 113.40 kg
Platform Capacity – Unrestricted 500 lb / 226.80 kg
Turning Radius – Outside 5 ft 9 in. / 1.75 m
Turning Radius – Inside 0 in. / 0 mm
Dimensional Data
Ground Clearance 4 in. / 0.09 m
Machine Height 6 ft 6 in. / 1.98 m
Machine Length 6 ft 2 in. / 1.87 m
Machine Width 2 ft 6 in. / 0.76 m
Platform Dimension A 2 ft 6 in. / 0.76 m
Platform Dimension B 6 ft 2 in. / 1.87 m
Platform Extension Length 3 ft / 0.9 m
Platform Height 18 ft 9 in. / 5.72 m
Platform Height – Lowered 2 ft 10 in. / 0.86 m
Platform Railing Height 3 ft 7 in. / 1.1 m
Tire Size 12.5 x 4 in
Wheelbase 5 ft 3 in. / 1.6 m
Reach Specifications
Platform Height 18 ft 9 in. / 5.72 m
Working Height 24 ft 9 in. / 7.54 m
